Idealpos Vogue

POS terminal with ultra-slim bezel and ergonomic design.

Idealpos Vogue
Idealpos Vogue
Idealpos Vogue
Idealpos Vogue

Key Features

  • IP66 Spill Proof
  • Intel CPU
  • Fanless
  • Powered Peripheral Support
  • Dual Hinge Design

Technical Specifications

Processor Intel® Celeron® 4305UE
Chipset CPU Integrated
System Memory 1 x SO-DIMM DDR4 slot, 4GB RAM as standard. Max. memory support up to 16GB.
TPM Intel F/W
LCD Size 15.6" 16:9 TFT LCD (LED backlight)
Bezel Slim-Edge 4.8mm Bezel Design
Brightness 350nits
Resolution 1920 x 1080 (16:9)
Touch True Flat Projected Capacitive Technology
Storage HDD/SSD 1 x SATA III (2.5”)
LAN Port/USB Port 1 x Gigabit Ethernet by RJ-45 / 2 x USB 2.0, 4 x USB 3.1
DC Input 1 x Mini Din 4P (DC + 19v only)
Speaker HD Audio, 2W Speaker x 2
Power Switch 1 x Power On/Off button
COM Port 2 x RJ48 (Support DC +0/5/12v by BIOS setting, default setting is 0v)
Cash Drawer 1 x RJ11 (Support DC + 12v or +24v (default)) port supports 2 Cash Drawers
OS Windows 10 IoT (64 bit)
Dimension (W x H x D mm) 362.8 x 304 x 175.3 mm
Operating temperature 0°C ~ 40°C, 10% ~ 90% RH, non-condensing
Storage temperature -20°C ~ 60°C, 10% ~ 90% RH, non-condensing
Material Main Unit: Die-Cast Aluminium
Colour Main Unit: Space Grey/Black
Power Adapter External adapter, DC Model : Voltage:+19VDC, Std. 180watt
(*VariIO PUSB)
External adapter, DC Model : Voltage:+19VDC, Std. 90watt
(*VariPOS 250S / VariIO Non PUSB)
Compliance Certifications CE, FCC, LVD, RoHS

Optional Accessories

2nd Display 10.1 ” Resolution 1280 x 800 (16:10 wide screen) USB Type, with/without True-flat P-cap 10 point Multi-touch
MSR ISO 3-Tracks Slim MSR USB Type
ibutton Dallas Key Reader, USB Type
RFID 13.56Mhz USB Type
Fingerprint DigitalPersona U.are.U 4500 Module, USB Type
Scanner 2D scanner, USB Type
